| Display Screen | 10-Inch Capacitive Touch Screen |
| Operating System | HC [Supports remote mobile app operation, intelligent mobile app interaction, remote access to processing records, alarm records, operation and maintenance video tutorials, and remote pattern making] |
| Pattern Generation Method | Automatic Generation; Patterns can be bound to parameters, with automatic parameter switching for different patterns and arbitrary adjustment of starting stitch points. |
| Maximum Head Sewing Speed | 4000 RPM |
| Speed Setting | 200–4000 RPM |
| Maximum Stitch Count | 200,000 Stitches |
| Maximum Pattern | 9999 |
| Head Model | 326G |
| Stitch Length | 0.1–12.7mm |
| Pattern Storage | 9999 |
| Needle Model | Groz-Beckert DP×17 12#, 14#, 16#, 18#; Different fabrics correspond to different needle specifications to reduce malfunctions. |
| Shuttle | Imported from Japan: Hirose Hook, KOBAN; Handles both light silk and heavy denim with ease. |
| Pocket Sewing | Real Pocket, Faux Pocket, Crescent Pocket |
| Presser Foot Type | Follower Presser Foot; Adjustable at any position based on different processes. |
| Presser Foot Height | 28mm |
| Outer Frame Lifting Height | 30mm |
| Inner Frame Lifting Height | 25mm |
| Spindle Motor | Direct-Drive Servo Motor |
| Electronic Control Display Language | Chinese, English [Additional languages can be added upon request] |
| Pocket Production Time | Faux Pocket: 16 seconds/unit, Real Pocket: 23 seconds/unit |
| Applicable Fabrics | Knit, Woven, Down, Cotton-Padded |
| Maximum Pocket Size | Length: 35mm–207mm, Width: 8mm–35mm |
| Transmission Method | Synchronous Belt and Slide Rail Structure; Smoother operation, more perfect stitches. |
| Infrared Positioning | Standard DANGER Multi-Group Infrared; Wavelength: 532nm, 635nm, 650nm, 780nm, 808nm, 980nm; Voltage: DC5V; Lifespan >10,000 hours [Color and quantity optional] |
| Laser | Standard Spite CO2 120W; High peak power, maintenance-free, lifespan over 100,000 hours. |
| X-Axis Y-Axis Motor | Delta 750W Servo, Inovance 750W Servo, HCFA 750W Servo [High-precision control, fast response, high torque output, diverse control methods, maintenance-free] |
| Suction | Medium-Pressure Blower for Smoke and Dust Suction; Air Volume: 17m³/min, Air Pressure: 1.9KPa, Noise<60dB, Power: 750W
|
| Mold Change Method | Quick Modular Mold Change; Partial component replacement, faster mold change speed. |
| U-Axis V-Axis Motor | Delta 400W Servo, Inovance 400W Servo, HCFA 400W Servo |
| Pocket Folding Adjustment Control | Dedicated Screen Page Adjustment, Pattern Memory, Supports Single-Side Pocket Folding and Triangular Pocket |
| Single Pocket/Zipper Pocket Positioning | Standard AirTAC Swing Arm Positioning, Front-Back Linear Guide Positioning for Easier Adjustment |
| Thread Break Detection | Standard Thread Break Detection BAS-326G |
| Bobbin Thread Detection | Computer-Set Bobbin Thread Usage Quantity, Automatic Prompt |
| Pocket Folding Method | Four-Direction Cylinder Front-Back Folding |
| Pneumatic Components | AirTAC; Good sealing performance, strong pressure resistance, no air leakage or jamming during long-term operation, strong buffering performance, built-in cylinder buffer to effectively reduce impact speed and extend lifespan. |
| Guide Rail Components | AirTAC; Golden guide angle and integrated design further enhance precision and stability. Slide rails use medium carbon steel, sliders use high manganese steel, ensuring reliability and durability. |
| Thread Tension Adjustment | Mechanical Adjustment/Electronic Adjustment |
| Loop Plate | 3240; Good heat resistance, strong adhesion, high insulation, low maintenance cost |
| Power Supply | AC220 |
| Air Pressure/Air Consumption | 0.6Mpa (5KG/m³), 22dm³/min |
| Net Weight | 780KG |
| Lock Case | Imported from Japan: Hirose Hook, KOBAN; More perfect stitches. High-toughness shrapnel prevents core spinning. |
| Equipment Dimensions | 1850×1310×1490 (Length × Width × Height) |
| Loop Plate | Customizable |
